The Foldable Shopping Cart unfolds and collapses in 2–3 seconds with one hand. Folded to a thickness of approximately 16 cm, it can be stored upright or flat, offering both portability and load-bearing performance. It's a Foldable Shopping Cart designed for home shopping, neighborhood store restocking, and light transport.

Foldable Shopping Cart Features

High Load-Bearing Capacity

The Foldable Shopping Cart's main frame is constructed from a combination of 20×0.9 mm and 16×0.8 mm carbon steel tubing. The bottom beam is reinforced with a "cross" shape and triangular bracing. The basket's bottom wire diameter is 3 mm, and the mesh is 25×25 mm. It has a static load capacity of 90 kg and a dynamic load capacity of 60 kg, and has passed 10,000 back-and-forth roll cycles and a 10° slope static stability test. Optimized center load distribution ensures no nodding when fully loaded in a straight line and no noticeable wiggle when turning, making it suitable for continuous handling of beverage cartons, rice bags, and fresh produce baskets.

Quick Folding

A dual-link and pull-and-lock mechanism allows for quick deployment and folding in 2–3 seconds. A mechanical secondary lock prevents folding during deployment. Folded to approximately 1000 × 400 × 160 mm, it stands upright when folded, eliminating space in entryways and aisles. The trunk is easily accessible with a single-handed pull, and the linked guide prevents entrapment. With a lifespan of ≥ 8,000 openings and closings, it withstands frequent store turnover and weekend family shopping.

Silent Casters

The Foldable Shopping Cart features 5″ 360° swivel front wheels and 8″ directional rear wheels. The tread is made of low-noise TPE and is 28 mm wide. Dual ball bearings reduce rolling resistance. Operating noise is ≤ 55 dB at 3 km/h on tiled surfaces, and there's no noticeable jerking across 15–20 mm gaps. Optional 8-inch pneumatic rear wheels are suitable for outdoor use on stone and asphalt surfaces. The integrated rear wheel brake pedal provides a clear feel and instantly locks during loading and unloading on slopes, increasing safety margins.

Large Capacity

The Foldable Shopping Cart basket measures approximately 600 × 400 × 325 mm, with a usable capacity of 75–80 L. The base platform measures 420 × 300 mm, allowing for additional stacking of cartons or rice bags. It comes standard with a 600 mm bungee cord and two lashing holes, capable of a single-point pull of ≥ 10 kg, allowing long items to be tied to the vertical pipe without slipping. The basket's 320 mm rim height makes loading and unloading easier, while the rounded corners prevent scratching clothing and packaging, making it suitable for frequent loading and unloading.

Corrosion and Weather Resistance

Powder coating thickness 80–90 μm, 72 h Neutral salt spray spray results in no blistering or noticeable gloss loss. Fasteners are galvanized bolts with lock washers. Welds are polished and sealed with primer, and can be wiped with common alcohol and neutral detergents for 1,000 times without fading. Operating temperature ranges from -20°C to 60°C, suitable for cold storage replenishment and summer exposure. Short-term outdoor parking on rainy days prevents rust and reduces daily maintenance costs.

Stable and Anti-Tipping

The 485 mm wheelbase and rearward-shifted center of gravity design place approximately 55% of the load on the rear axle, enhancing straight-line stability. The 150 mm ground clearance balances passability with underbody protection. The minimum turning radius is ≤ 1 m, allowing for quick U-turns in elevators and narrow aisles. The handlebars can be adjusted 15° to the left and right for easy steering, ensuring no foot-skipping during fully loaded turns. The pedal brake and frame stiffeners work together to prevent forward tilt in sudden stops.

Ergonomic Comfort

The telescopic push handle has three height settings: 980/1020/1060 mm, suitable for heights between 155 and 190 cm. EVA The 20 mm thick handle is non-slip for wet or dry hands. The empty cart weighs approximately 6.8–7.6 kg, making it easily liftable by one person. The force required for long-distance linear propulsion is approximately 25–35% lower than that of bearingless casters, reducing the effort required for continuous handling.

Easy Maintenance and Shipping

The Foldable Shopping Cart casters feature M8 quick-release nuts and standard 608ZZ bearings, allowing for easy replacement in 10 minutes. The side hooks, straps, and foot covers are all universal and easily available. The entire cart is 70% pre-assembled, allowing for easy unpacking and use in approximately 3 minutes. The dimensions of a single cart are approximately 1020 × 420 × 170 mm, with a gross weight of approximately 8.2 kg. A 20′ GP cart is recommended to carry 450–500 carts, improving cabinet utilization and landed cost advantages.

Foldable Shopping Cart Applications

Weekend shopping for urban families

From underground garages to elevators and entrance doors, involving ramps and joints. 75–80 L Foldable Shopping Cart The cart can easily carry both beverage crates and fruit and vegetable boxes. Its 8-inch rear wheels provide stability over speed bumps, and its folded thickness of 16 cm allows it to stand against a wall without taking up space in the entryway. A pedal brake prevents slipping during loading and unloading on slopes, and the three-position push handle height allows for comfortable maneuvering for people of different heights, making weekend shopping more efficient and effortless.

Apartment Basement Garage

Narrow parking spaces and single lanes require flexible U-turns. The minimum turning radius is ≤ 1 m, and the front universal steering and rear steerable steering provide responsive maneuvering at low speeds. The Foldable Shopping Cart has a 15–20 mm gap for smooth traversal, and its TPE wheels offer reliable grip on slippery surfaces in rainy weather. After loading and unloading, it folds flat with a single click and fits flat against the side of the trunk, eliminating space and making daily storage easier.

Community Fresh Food Store Backyard

Short-distance, high-frequency handling from cold storage to shelves requires low noise and moisture resistance. The TPE silent tires are slip-resistant on wet surfaces, and the powder coating resists condensation. 600×400 turnover boxes fit directly into the basket, allowing for smooth U-turns even in aisles as narrow as 1 meter. After closing, the basket folds upright to free up space for easy cleaning at night, and can be quickly restored and put back into use the next day.

Restocking a farmers' market stall

Maneuvering through the early morning traffic requires flexibility and durability. The 5" universal wheels steer flexibly, keeping the foldable shopping cart's width within 480 mm without skidding. Elastic cords secure the vegetable basket to prevent it from rolling. When closing the stall, it can be stowed in the van's side compartment along with the tent poles and folding table. Once folded, it stands upright without rolling, significantly improving stall setup and dismantling efficiency.

Laundromat Aisle

The materials are engineered for wet environments and detergents. The powder-coated finish and galvanized fasteners are resistant to alcohol and detergents, and can hold 10-15 kg of clothing without losing shape. The front universal wheels and rear directional steering allow for flexible passing in narrow aisles, while the quiet operation during nighttime hours ensures peace of mind for neighboring shops. The pedal brake on the ramp's exterior provides secure parking and enhances the customer experience.

Campus Dormitory Moving

Transportation between buildings is often necessary for new students arriving or graduates moving out. Folding allows for easy access to elevators and around corners. The 3mm mesh supports loose books, and the 8" rear wheels provide stability when climbing stairs. The EVA handle provides long-distance push without pinching the hand, and the three-position push handle height adjustment accommodates different students, saving effort and ensuring safety during handling.

E-commerce forward warehouse picking

Crowded shelves require a tight turning radius and stable linear motion. The dual-bearing casters have low rolling resistance, making long aisles easier to maneuver. "Upper basket, lower tray" design divides the loading area for refrigerated and ambient temperature items, and side strapping holes for hanging pick lists and color codes facilitate clear batch verification. At the end of a shift, the unit folds against the wall, freeing up aisle space and facilitating smoother inventory handling.

Exhibition setup and dismantling

Crowded aisles and multiple floor cable ducts. The 8-inch rear wheels offer ample clearance, allowing roll-up stands and sample boxes to be placed upright and secured with bungee cords. Nighttime setup and dismantling also operate quietly, eliminating disturbances to surrounding booths. Multiple units can be moved simultaneously for dismantling, and after loading, they can be folded and stored under exhibition tables or on the side of the truck's trunk, saving transportation time and labor costs and improving venue turnover efficiency.
